WARNING
These are not protected cells and are for making packs
CAUTION: when working with Li-ion cells, they are very sensitive to charging characteristics and may explode if mishandled.
Protective Circuit Board is required when making packs
User should have enough knowledge on Li-Ion rechargeable batteries in charging, discharging,and assembly before use.
Put the batteries in fire-proof container
Never leave batteries unattended when charging
Do not put batteries on wood surface or carpet when charging
We are not resopnsible for damage of any modification to the batteries in form, shape or made into packs
We are not responsible for any damage caused by misuse or mishandling of theses Li-Ion batteries
Product Specifications:
Capacity: Nominal 800 mah
Dimensions: 14Dx49Hmm
Weight (Typical) Approximate.21 g
Nominal working voltage: Average 3.7V
Peak Voltage: 4.2V
Discharge Cut-off Voltage: 2.75V
Internal Resistance: <80 mOhm
Cycle Performance: 85% of initial capacity at 300 cycles
Cycle life: > 300 cycles
Max. Charging current: 1C ma
Max. Discharging current 2.5C ma (for continuous discharge)
|
|
